Inside Git: How It Works and the Role of the .git Folder

In today’s blog, we basically try to understand how git is actually working under the hood. Before starting this blog, if you’re unfamiliar with Git, please follow these two introductory blogs first, then return to read this blog.

Blog 1: Why We Need A Version Control System

Blog 2: Basic Command of Git

So let’s start exploring how Git works internally.

As you can see, we initialized an empty Git repository, which created the .git folder—now let’s look inside and see what it actually contains.

Let’s look at the .git folder

As you can see, it contains a few folders like hooks, info, objects, and refs, along with some files such as config, description, and HEAD. Now we’ll go through each of them one by one and try to understand how they work. Let’s start by opening the HEAD file.

As you can see, it contains a ref (reference) that points to a folder path: refs/heads/master. Let’s take a look at that now. Inside the refs folder, we can see two folders: heads and tags.

For now, both folders are empty. If we look at the description file, it contains the repository name. To change the repository name, we need to edit this file.

Next, we have the info folder, which contains a file called exclude. For now, it’s empty, but this file is used to tell Git to ignore certain files—we’ll definitely look at it later. After that, there’s the hooks folder, which contains some sample scripts that we can use if we need any special use cases.

As you can see, there’s a pre-commit.sample script where you can write your own custom logic. If you remove the .sample extension, that logic will run automatically every time you commit your codebase.

Now, to understand how this works, let’s create a file called text.txt.

We run git add . and git commit, which adds all files to the staging area and creates a commit. After doing this, we can immediately see changes inside the .git folder. First, a index file is created, and inside the objects folder, a new directory 55 appears.

Now, to understand these changes, we first need to understand what Git objects The folder actually is.

Git has three objects

1. Blob

2. Tree

3. Commit

Let’s understand the blob first.

Git uses a special technique to store file changes. It uses a SHA-1 hash to identify a file—almost like a tag—and the actual file content is stored as a blob. In simple terms, a blob represents the actual content of a file.

A blob stores raw file content

• No filename

• No permissions

• No path

• It stores the just byte

If text.txt contains:

this is a plain text file.
Give it a number 1

How blob content is stored

Internally Git stores:

blob <size>\0<content>

Then a SHA-1 hash is calculated from that content. If the content is exactly the same, it generates the same SHA-1 hash because it’s a mathematical function. But even a single space or a new line will change the content and produce a completely different SHA-1 hash.

In Git, to see the staged blobs, we can run this command:

It returns a hash—in our case, 559b906315547fcdf98e1b77dbe23f9969abb935. If you look closely, the first two characters are 55, which matches the folder name created inside the objects directory during the git add . command. The remaining characters are used as the filename, and that file stores the actual content.

To see the hash file content, we can use this command:

git cat-file -p <sha1-hash>
# here -p stands for pretty-print ( to see the binary content we use this)

To extend our discussion, let’s create a copy of the text file—both files have the same content.

And then, let’s stage the new file as well.

And in the objects folder, no new folder is created.

Git actually saves storage this way. When the content is the same, Git does not create any duplicate data—it reuses the same SHA-1 hash until the file content changes. As you can see in the output, we have two files in the staging area, but both of them point to the same hash.

To see the type of object hash, we can use this command

git cat-file -t <sha-1 hash>
# -t stands for type

Now you may have what is inside the index file we have here

To see the index file conent we already use that command

git ls-files --stage
# output
# 100644 559b906315547fcdf98e1b77dbe23f9969abb935 0       text-copy.txt
# 100644 559b906315547fcdf98e1b77dbe23f9969abb935 0       text.txt

Column 1 → 100644 (THIS IS IMPORTANT)

What it means in plain English

100644 = **file type + permissions (**Git borrows this from Unix file system rules.)

100 | 644

File type

File permissions

This part decides who can read/write/execute the file.

644 = rw-r--r--

Let’s try to figure out how this tells the permission for each file
Computers think in bits

A bit can be:

0 = off
1 = on

Permissions need 3 independent switches:

• Read

• Write

• Execute

Assume Switch Position is

Read    Write   Execute
  2       1        0

# Bit position:   2²   2¹   2⁰
# Decimal value:   4    2    1

Because you can add them and always know what’s enabled.

What if values were random? (why NOT 3, 5, 6?)

read = 3
write = 5
execute = 6
# 3 + 5 = 8 ❌ what is 8? Not Understandable

Binary weights guarantee: Every combination is unique and reversible.

Now, let’s understand the Second and Third objects of Git, which are the tree and the commit together

Tree:

A tree is Git’s snapshot of a folder.

• Not a file.

• Not a commit.

• A directory structure at a specific moment.

Make a commit of my Two Created File Text and text copy both

Note: After Running This Command It creates a new File Which is COMMIT_EDITMSG

This file stores the actual commit mesage temporary to save it further we provide during the commit command

Now, to understand the Tree and Commit Let’s run This Command

git log

As you can see, it also gives a SHA-1 hash. Let’s check the content of that first.

git cat-file -p <sha-1 hash>

As you can see, it shows a tree with the hash ad031163ef52fb6ab5e1e, along with the author name, committer name, and the commit message.

Now, let’s copy the tree hash and try to view its content using this command.

git cat-file -p <sha-1 hash>

Let’s print the type of it using this command

So we can think of a tree as the directory structure for our code files. Here, we can see that it contains two blobs. To move our understanding forward, let’s create another folder with some content.

And commit it with the message “z feature added.”

As a result, we can see a few changes.

The first change we notice is in the COMMIT_EDITMSG file.

As you can see, we now have two commits.

Now, everything should be clear.

The object type of this hash is

Let’s understand the output here,

$ git cat-file -p 379a752
tree 2b7a20fe16cb153fc71a4ca8598ec1208fafecc2 # this is the current tree sha 1 hash
                                              # were current commit is poiting
parent cc2a85709f2cf0a75b8fe6e8fa075c3b2b8a1550 # This is the Parrent tree sha 1 hash
author Pallab Karmakar <ookarmakarpallab1212@gmail.com> 1768467910 +0530 # Author Metadata
committer Pallab Karmakar <ookarmakarpallab1212@gmail.com> 1768467910 +0530

adding z feature # Actual Commit Message

The complete workflow actually looks like this.

Let’s try to break down the Staging and Commit Internals working mechanisms

What happens when you run git add .

• Git does NOT store files by name or folder

• It only cares about file content

Step-by-step:

• Git reads the content of each modified/new file

• For each file, Git:

  • Takes the raw file content

  • Prepends a header like:

      blob <size>\0


  • Calculates a SHA-1 hash of this data

• This hash uniquely identifies the file content

Object storage:

• Git stores the content as a blob object

• Blob is saved inside:

    .git/objects/xx/yyyyyyyyyyyy...


  where:

  • xx = first 2 characters of the SHA-1

  • yyyy... = remaining 38 characters

• If two files have identical content, Git:

  • Creates only one blob

  • Both files point to the same SHA-1

Staging area (index):

• Git updates the index file

• Index maps:

    filename → blob SHA-1


• At this point:

  • Files are staged

  • No commit exists yet

What happens when you run git commit

Tree creation:

• Git reads the index

• It creates a tree object

• The tree:

  • Represents a directory snapshot

  • Maps:

      filename → blob SHA-1


• Each folder becomes its own tree (nested trees if needed)

Commit object creation:

• Git creates a commit object

• The commit contains:

  • Tree SHA-1 (root directory snapshot)

  • Parent commit SHA-1 (if any)

  • Author name & email

  • Committer info

  • Commit message

Relationships:

Commit → Tree → Blobs

• Commit points to the tree

• Tree points to blobs

• Blobs store actual file content

After the commit is done

• A new file appears:

    .git/COMMIT_EDITMSG


  (temporary, for commit message)

• HEAD now points to:

    refs/heads/master → commit SHA-1


• Git history is updated

• Working directory is now clean

Conclusion:

• Git stores everything as objects, not as plain files.

• Blobs store the actual content of files.

• Trees represent directory structures and map filenames to blobs or other trees.

• Commits store metadata and point to a single root tree.

• Git uses SHA-1 hashes to uniquely identify every object.

• If two files have the same content, Git stores only one blob and reuses the same hash.

• Any small change in content creates a new SHA-1 hash.

• The index (staging area) links files to blobs before committing.

• The objects folder stores all blobs, trees, and commits in a compressed form.

• The HEAD reference points to the current commit.

• Each new commit creates a new tree if the directory structure changes.

• This design makes Git fast, storage-efficient, and reliable.
